CS single cylinder hydraulic cone machine series

CS single-cylinder hydraulic cone crusher is a new high-efficiency crusher independently developed and designed by Hengji Intelligent Equipment based on many years of experience and extensive absorption of advanced crusher technology from the United States and Germany.This cone crusher integrates mechanical, hydraulic, electrical, automation and intelligent control technologies and represents the world's advanced crusher technology.

Get Product Quote

CS single cylinder hydraulic cone machine series

获取产品报价

Product features

Greater processing capacity, safer and smarter, more efficient cone crusher

Feed size: 0-370mm

Production capacity: 45-2000 tons/hour

Applicable materials: granite, diabase, basalt, river pebbles, limestone, dolomite, Metallic ores and non-metallic ores, etc.

Product technical parameters

型号	腔型	给料口最大尺寸 (mm)	紧边排料口尺寸 (mm)	处理能力 (t/h)	标配装机功率~最大装机功率 (kW)	重量 (t)
CS430	EC(超粗)	360	25-54	125-415	132～160	12
	C(粗)	300	22-48	110-340
	MC(中粗)	235	22-48	95-260


CS440	EC(超粗)	450	35-54	265-640	220~280	19.3
	C(粗)	400	29-51	225-490
	MC(中粗)	300	25-51	195-445



CS680	EC(超粗)	560	41-70	350-1050	315~355	35.7
	C(粗)	500	38-70	320-930




CH430	EC(超粗)	185	13-38	70-220	132~160	9.2
	C(粗)	145	13-38	65-150
	MC(中粗)	115	10-32	55-190
	F(细)Fine	90	8-32	60-180
	MF(中细)	75	8-25	50-135
	EF(超细)	50	10-25	55-120
CH440	EC(超粗)	215	16-44	115-415	220~250	14.3
	C(粗)	175	13-38	100-405
	MC(中粗	140	13-38	95-350
	F(细)	110	13-38	115-300
	MF(中细)	85	8-51	90-510
	EF(超细)	70	10-51	95-360
CH680	EC(超粗)	275	16-51	175-655	315~355	24.2
	C(粗)	215	16-44	170-645
	MC(中粗)	175	16-44	160-500
	F(细)Fine	135	16-70	195-1330
	MF(中细)	195	13-70	190-1865
	EF(超细)	85	13-70	195-1890

Remarks:

The specific gravity of the pile is 1.6t/m³. The width of the feed opening is ≥600mm for large size, and 300-600mm is for medium size.
2. The product pictures, models, data, functions, performance, specifications, etc. on this website are for reference only. Henderson Intelligent Equipment may improve the above content. For specific information, please refer to the actual product and product manual.Unless otherwise specified, the right to interpret the data involved in this website belongs to Henderson Intelligent Equipment.

Product application

Working principle of CS series single-cylinder hydraulic cone crusher

When CS series single-cylinder hydraulic cone crusher works, the motor drives the equipment transmission shaft to rotate through the pulley and V-belt, and the transmission shaft drives the eccentric sleeve to rotate through the large and small bevel gears, and the moving cone passes through the main shaft. Under the action of the eccentric sleeve, the movable cone and the fixed cone sometimes approach and sometimes move away from the rolling mortar wall. The material is continuously squeezed, impacted and broken in the crushing cavity between the rolling mortar wall and the crusher. The broken materials Discharge from the bottom.
