PE jaw crusher-Crusher_Jaw crusher

PE jaw crusher

As a classic primary crushing equipment with stable performance, PE jaw crusher has been widely used in fields such as metal ore crushing, non-metallic ore crushing, construction aggregate crushing, and sand making.

Get Product Quote

PE jaw crusher

获取产品报价

Product features

Classic design, simple structure, reliable working performance

Feeding particle size: 50-1040mm

Production capacity: 50-900 tons/hour

Applicable materials: granite, marble, basalt, limestone, quartz stone, river pebbles, iron ore, copper ore wait

Product technical parameters

型号	进料口尺寸 (mm)	最大进料粒度 (mm)	出料口调整范围 (mm)	处理能力 (t/h)	偏心轴转速 (r/min)	电机功率 (kw)	重量（t）
PE500×750	500×750	425	50-120	45-100	275	55	10.1
PE600×900	600×900	500	60-160	180-150	250	55-75	15.5
PE750×1060	750×1200	630	100-220	220-320	250	110	28
PE900×1200	900×1200	750	100-220	300-700	200	160	43
PE1200×1500	1200×1500	900	150-230	500-1000	180	250	85
PE1300×1600	1300×1600	1000	180-280	800-1300	160	400	98

Remarks:

The specific gravity of the pile is 1.6t/m³. The width of the feed opening is ≥600mm for large size, and 300-600mm is for medium size.
The product pictures, models, data, functions, performance, specifications, etc. on this website are for reference only. Hengji Intelligent Equipment may improve the above content. For specific information, please refer to the actual product and product manual.Unless otherwise specified, the right to interpret the data involved in this website belongs to Hengji Intelligent Equipment.

Product application

Working principle of PE jaw crusher

PEX jaw crusher is powered by a motor. Through the motor pulley, the V-belt and sheave drive the eccentric shaft, so that the movable jaw reciprocates according to the predetermined trajectory. The material in the crushing cavity composed of the jaw plate and the side guard plate is crushed, and the finished material is discharged through the lower discharge port.
